When an animal comes in contact with APFS, an Electrical impulse runs through it's body, causing a sudden muscular spasm. The animal receives a painful, but harmless shock, and has no further desire to approach the fence again.

The heart of the fence is the energizer. The electric fence energizer is powered by a 12-volt battery or charged by Solar power or a 230-volt AC electrical outlet. The fence energizer produces low ampere, high voltage electrical pulse which acts as a deterrent to wildlife. It produces high voltage impulse of approximately 8KV every 1.2 seconds. The impulse acts for approximately 3 micro-seconds and has a current up to 10 amps.

Under normal circumstances the posts are spaced 20-25 feet apart. In certain areas where the elephant menace is greater a two-tier or a three-tier configuration with a single or two wires 10-15 feet from the main fence at a height of 6.5 - 7 & 3 - 3.5 feet ( head/shoulder height of adult and young elephant ) can be adopted.

The elephants would have to negotiate the first fence before they reach the main fence. This would work effectively. In multiple tier systems, the posts can be fenced 50-60 feet apart. Standing trees can be used for the inside line. An energizer could be used with each line if necessary. This design has effectively controlled elephants in India and Africa.

Most effective and viable perimeter security alternative that meets present day needs.

Maximum protection against intrusion, theft, pilferage, sabotage is an active deterrent - not only delays / denies entry to a secured area but detects intrusion and indicates the area of attempted intrusion on a graphic panel in the Control Room.

Can be added to or replaces any existing perimeter wall, chain link fence-Full Fence or Wall Top and integrated with Access Control Systems, Security Lighting, CCTV Systems, Auto Dialers, can activate a hooter, siren or flood lights on intrusion alarm.

The Active Security Fences are powered by a low impedance ENERGIZER which sends out high voltage monitored pulses into the fence at controlled intervals. An intruder or trespasser gets a very sharp, short and painful shock.

The Active Security Fence is the physical barrier but the shock is the real barrier - a psychological barrier created in mind of the person, who has experienced the shock!!!. The shock given by the fence is completely safe as it lasts only 3 millionths of a second with energy output of 4-5 joules, an internationally accepted standard for such types of fences, worldwide.

• Round the clock Vigilance - 24/7 x 365 days · Provides an ACTIVE DETERRENT to the would be intruder. Intruder gets a very sharp, short and painful but non-fatal / safe shock.
• Zero Downtime - Works on SOLAR POWER also.
• Customized design, quality and rugged construction.
• Trouble-free User friendly system, minimal maintenance.
• System reliability ensures virtually NO FALSE ALARMS.
• Unaffected by sun, wind, rain, snow, sleet, fog, birds or wild animals.
• Reduces Insurance, security and management costs, cost effective operation - short pay back period.
